XR — 6DoF All-In-One
QXR-06-03
6DoF XR with 3Kx3K per-eye passthrough | 4640x2160 display | 24 PPD.
01 · Position in category
QXR-06-03 sits in QWR's 6DoF standalone XR bucket alongside seven sibling SKUs. It steps up to Snapdragon XR2 Gen 2 with 16 GB RAM — tying the bucket's flagship QXR-06-07 for the highest RAM figure outside that model — paired with a pancake 4640×2160 display at the bucket's widest 110° FoV, and dual passthrough cameras specified at 3K×3K per eye. Battery is listed as >5000 mAh at 500 g.
02 · Compute
| Processor | Snapdragon® XR2 Gen 2 |
| Memory | 16 GB |
| Storage | 128 GB |
16 GB RAM on Snapdragon XR2 Gen 2 ties the bucket’s flagship QXR-06-07 for the highest RAM figure among these 8 SKUs — the only other standalone model to reach it.
03 · Display
| Display Type | Fast LCD |
| Resolution | 4640 x 2160 |
| Refresh Rate | 90Hz |
| Field of View (FoV) | 110° |
| Optics | Pancake Lens |
110° FoV is the widest disclosed field of view in the bucket — the rest range from 90° to 105°, and the flagship QXR-06-07 sits at 103°.
04 · Interpupillary Distance (IPD)
| Compatibility Range | 56mm - 72mm |
| IPD Adjustment | Manual |
05 · Tracking & Sensing
| Tracking Cameras | 4 x greyscale global shutter cameras |
| Passthrough Camera | 2 |
| Passthrough Resolution | 3K x 3K per eye |
| Sensors | 2 visible light cameras / Accelerometer, Gyroscope |
| Hand Tracking | Supported |
Passthrough is specified at 3K×3K per eye, the highest disclosed passthrough resolution in the bucket — QXR-06-02 is the only other SKU to disclose a per-eye figure, at 1600×1600.
06 · Input & Control
| Controller Count | 2 |
| Controller Type | 6 DoF Controller |
| Controller Charge | External Batteries |
07 · Connectivity
| Wi-Fi | Supported |
| Bluetooth | Supported |
| Interface | USB-C |
| Wireless Operation | Yes |
08 · PC & Streaming
| PC Streaming Wireless | Supported |
| PC Streaming Wired | Supported |
| PC Client Application | Yes |
| Screen Mirroring | Supported |
09 · Audio
| Output | Dual Speakers |
| Speakers | Integrated surround speakers |
| Microphones | Built-in |
10 · Battery
| Battery Solution | Internal Battery |
| Battery | >5000 mAh |
| Controller Battery | External Batteries |
11 · Design
| Ergonomics | Battery at the Back |
| Weight | 500 gms |
| Weight Distribution | Weight Distributed |
12 · Across the category
| QXR-06-03 | QXR-06-01 | QXR-06-02 | QXR-06-04 | QXR-06-05 | QXR-06-06 | QXR-06-07 | QXR-06-10 | |
|---|---|---|---|---|---|---|---|---|
| SoC | Snapdragon® XR2 Gen 2 | Snapdragon® XR2 Gen 1 | Snapdragon® XR2 Gen 1 | Snapdragon® XR2+ Gen 2 | Snapdragon® XR2 Gen 1 | Snapdragon® XR2+ Gen 2 | Snapdragon® XR2+ Gen 2 | Snapdragon® XR2 Gen 2 |
| Display | Fast LCD | Fast LCD | Fast LCD | Fast LCD | Fast LCD | Micro-OLED | Micro-OLED | Fast LCD |
| Battery | >5000 mAh | 5500 mAh | >4000 mAh | 5500 mAh | 5500 mAh | — | 5060 mAh | 6000 mAh |
| Weight | 500 gms | 490 gms | 500 gms | 540 gms | 450 gms | 235 gms | 650 g | <430 gms (incl. headband, face mask) |
FAQ
Common questions
What makes QXR-06-03's display different?+
It runs a pancake 4640x2160 display at 110 degree field of view, the widest disclosed FoV in the bucket. The rest range from 90 to 105 degrees, and the flagship QXR-06-07 sits at 103 degrees.
What is the passthrough resolution on QXR-06-03?+
3K by 3K per eye, the highest disclosed passthrough resolution in the bucket. QXR-06-02 is the only other SKU to disclose a per-eye figure, at 1600x1600.
