VR — 6DoF
QVR-06-01
Standalone 6DoF. Hand tracking, distance sensing, 4 cameras, 5500 mAh, 490 g.
01 · Position in category
QVR-06-01 sits in QWR's 6DoF standalone lineup alongside its closest current sibling, QXR-06-10. Both run on Snapdragon XR2 silicon with Fresnel optics and wireless PC streaming, but QVR-06-01 keeps the earlier XR2 Gen 1 SoC and a 96° FoV where QXR-06-10 moves to XR2 Gen 2 and widens to 115° FoV with up to 120Hz on its higher-spec display batch. QVR-06-01 does inside-out tracking with hand tracking and distance sensing and no passthrough camera; QXR-06-10 swaps that for 6DoF touch controllers plus dual 16MP RGB cameras for full-colour passthrough, and is the lighter of the two at under 430 g against QVR-06-01's 490 g.
02 · Compute
| Processor | Snapdragon® XR2 Gen 1 |
| Memory | 8 GB |
| Storage | 128 GB |
Snapdragon XR2 Gen 1 — QXR-06-10, its closest current sibling, runs the newer XR2 Gen 2.
03 · Display
| Display Type | Fast LCD |
| Resolution | 3664 x 1920 |
| Refresh Rate | 90Hz |
| Field of View (FoV) | 96° |
| Optics | Fresnel lenses |
| Screen Size | - |
96° FoV, flat 90Hz — QXR-06-10 shares Fresnel optics and resolution but widens to 115° FoV, with up to 120Hz on its higher-spec display batch.
04 · Interpupillary Distance (IPD)
| Compatibility Range | 58mm / 63mm / 68mm |
| IPD Adjustment | Automatic |
58 / 63 / 68 mm, automatic — QXR-06-10 covers a wider 54–74 mm range via software adjustment in 1mm steps.
05 · Tracking & Sensing
| Tracking Cameras | 4 x greyscale global shutter cameras |
| Passthrough Camera | - |
| Passthrough Resolution | - |
| Sensors | 3-axis Gyro / 3-axis ACCL sensor |
| Infrared | - |
| Eye Tracking | - |
| Distance Sensing | Supported |
| Hand Tracking | Supported |
Distance Sensing and Hand Tracking are both marked Supported here; QXR-06-10 leaves both unset, pairing its 4 tracking cameras with 2 RGB cameras for full-colour passthrough and relying on its 6DoF controllers for spatial interaction instead of bare-hand tracking.
06 · Input & Control
| Controller Count | 2 |
| Controller Type | 6 DoF Controller |
| Controller Charge | External Batteries |
| Voice Control | - |
07 · Connectivity
| Wi-Fi | Supported |
| Bluetooth | Supported |
| Interface | USB-C |
| Wireless Operation | Yes |
08 · PC & Streaming
| PC Streaming Wireless | Supported |
| PC Streaming Wired | Supported |
| PC Client Application | Yes |
| Screen Mirroring | Supported |
09 · Audio
| Output | Dual Speakers |
| Speakers | Integrated surround speakers |
| Microphones | Built-in |
| 3.5 mm Audio Jack | - |
10 · Battery
| Battery Solution | Internal Battery |
| Battery | 5500 mAh |
| Controller Battery | External AAA Batteries |
11 · Design
| Ergonomics | Battery at the Back |
| Touch Pad | - |
| Memory Card Slot | - |
| Weight | 490 gms |
| Weight Distribution | Weight Distributed |
| Diopter Adjustment | - |
490 g — the heavier of the two; QXR-06-10 targets under 430 g.
12 · Across the category
| QVR-06-01 | QVR-06-04 | |
|---|---|---|
| SoC | Snapdragon® XR2 Gen 1 | Snapdragon® XR2+ Gen 1 |
| Camera | — | — |
| Display | Fast LCD | Fast LCD |
| Battery | 5500 mAh | 5300 mAh |
| Weight | 490 gms | 350 gms |
